GLLD (A) chain belt feeder is a new product improved by our company and China University of Mining and Technology on the basis of GLLD chain belt feeder. The conveyor chain belt of the feeder is replaced by a customized rubber belt. The steel armor belt not only retains the advantages of the chain drive of no deviation, no slippage, and accurate rotation, but also has the advantages of light weight, low noise, low cost, more convenient maintenance, no coal scattering, and no leakage of materials.
GLLD (A) type chain-belt feeder is mainly used for the transfer of various fine and loose materials. Replacement product.
At present, the GLLD (A) chain-belt feeder has obtained national invention and utility model patents (patent numbers: 2020112607542, 2020226153860), and has obtained mining product safety mark certificates (certificate numbers MCN210098, MCN210095, MCN210092, MCN210094) .
Features
- The patented technical machine that uses sprockets to drive the chain to drive the conveyor belt to transmit materials, the chain transmits power, the conveyor belt meter plays the role of carrying materials, and the chain drives the conveyor belt and the material to move, which can realize the process of conveying materials without sprinkling and transmission. No slippage; high reliability of transmission operation, low resistance, low driving power (feeding rate 1000t/h 5.5kw; 2800t/h-7.5kw energy consumption), high efficiency;
- The feeding amount is large and stable, the operation is stable, the adjustment is convenient (manual or variable frequency stepless speed regulation), and the noise is small;
- With the advantages of belt feeder and chain belt feeder, there is no belt feeder, ordinary steel belt feeder belt deviation, slippage, wear, belt need to be frequently tensioned, replaced and other problems , the maintenance workload is small, and the maintenance is convenient;
- The whole machine has reasonable structure, small size, light weight, convenient installation and adjustment, small transmission wear and long service life;
- It can replace the current reciprocating feeder, and it is the replacement product of the existing continuous feeder such as belt type and ordinary steel armor belt type feeder.
